| Ampere rating (A) | Amp code | Marking Code | Max Voltage rating (V) | Interrupting rating | Nominal cold resistance (Ohms) | Nominal melting i2t(A2sec) | Nom Voltage Drop (mV) | Nom Power Dissipation (W) |
| 0.125 | 0466.125 | B | 125 | 50A @125 V AC/ DC |
4.000 | 0.0004 | 552.66 | 0.0691 |
| 0.200 | 0466.200 | C | 1.160 | 0.00055 | 254.28 | 0.0509 | ||
| 0.250 | 0466.250 | D | 0.710 | 0.001 | 207.01 | 0.0518 | ||
| 0.375 | 0466.375 | E | 0.350 | 0.0028 | 169.18 | 0.0634 | ||
| 0.500 | 0466.500 | F | 63 | 50A @63 V AC/DC | 0.248 | 0.006 | 158.47 | 0.0792 |
| 0.750 | 0466.750 | G | 0.111 | 0.0276 | 98.65 | 0.074 | ||
| 1.000 | 0466001. | H | 0.076 | 0.0423 | 89.94 | 0.0899 | ||
| 1.250 | 04661.25 | J | 0.059 | 0.064 | 85.71 | 0.1071 | ||
| 1.500 | 046601.5 | K | 0.048 | 0.1103 | 82.97 | 0.1244 | ||
| 1.750 | 04661.75 | L | 0.039 | 0.1323 | 80.73 | 0.1413 | ||
| 2.000 | 0466002. | N | 0.031 | 0.2326 | 78.73 | 0.1575 | ||
| 2.500 | 046602.5 | O | 50A @32 V AC/DC | 0.024 | 0.3516 | 76.99 | 0.1925 | |
| 3.000 | 0466003. | P | 32 | 0.020 | 0.576 | 75.99 | 0.228 | |
| 4.000 | 0466004. | S | 0.014 | 1.024 | 74.50 | 0.298 | ||
| 5.000 | 0466005. | T | 0.011 | 1.600 | 73.75 | 0.3688 |
